The Rosette Nebula
in Mapped Color


About This Photograph

Here is a unique view of an otherwise oft-photographed object. Special filters were used to isolate light emitted by individual atoms within the vast cloud of gas and dust. These were then color-coded so that the distribution of the different elements could be more easily discerned, a result that is as scientifically valuable as it is pleasing to the eye. Red indicates the light given off by sulphur atoms when stimulated by the intense ultraviolet light streaming from the young, hot stars at the center of the nebula. Similarly, green represents the light from excited hydrogen atoms, and blue the light of oxygen.



Technical Details

Optics:TeleVue NP-101.
Mount:Astro-Physics AP1200GTO.
Camera:STL-11000XM.
Filters:Custom Scientific 5nm S-II, H-alpha, O-III.
Dates/Times:6 February, 9,17 March 2004.
Location:my backyard observatory in Austin, Texas.
Exposure Details:S-II: 2 hours.H-alpha: 4.33 hours.O-III: 3.5 hours.
Processing:To generate the color, the three emission-line images were first histogram-normalized, so that they each covered the same total range of brightness. These were then combined into an RGB image, and finally the H-alpha data was used for the luminance (brigh



Publication Data for this Photograph

Date Publication Type
2006-11-00 The NewAstro Zone System for Astro Imaging,
p. 209
Book
2004-06-24 Space.com,
Image of the Day
Web Site
